AVTek Interactive monitor TouchScreen 5 LITE 55 1TV135
Информация за продукта
AVTek Interactive monitor TouchScreen 5 LITE 55 1TV135 Обобщение
AVTek Interactive monitor TouchScreen 5 LITE 55 1TV135
Description
The new generation of Android 7.0 offers faster components and a higher version of the operating system, which makes support for the monitor even smoother and will allow you to install more demanding applications.
A built-in application (inactive version) for wireless video streaming allows you to connect to 8 computers or mobile devices at once and display up to four images at the same time. Wireless transmission of video, sound and touch makes cooperation even more convenient and eliminates the need to connect each computer directly to a monitor. In addition, it is possible to extend it by Avtek Share, a hardware solution that will allow you to connect to your computer without installing additional software on it, connect the dongle to the USB port and press the button.
Over-the-air software updates keep your monitor up to date with the latest features and applications over time. The user will easily install the update when it is available and will not be bypassed by future changes.
TouchScreen 5 monitors are fully prepared to support 4K/UHD resolution. The advanced LG panel with 3840 x 2160 resolution and 60Hz refresh rate is responsible for displaying the image. The chassis features a new, faster OPS connector for an optional PC and HDMI 2. 0 ports for connecting any modern equipment.
Thanks to the unique solution of shared USB ports on the front of the monitor, once connected to the USB stick will be available on both Android and the built-in OPS computer without the need to move between ports.
The new version of the note taking tool in the Lite series not only allows you to mark notes on any image or monitor like an interactive whiteboard, but it is also equipped with additional tools to help with presentations, lessons and meetings, e. g. stopwatch, timer, spotlight and voting system.
The voting tool called from the pop-up shortcut bar available on each source allows you to ask any question, collect answers and discuss them quickly. And it doesn't matter if you're viewing a presentation, an Android browser or an image from an external source like a laptop.
The monitor lockout features are dedicated to the school environment and are suitable for use in crowded areas. USB Disk Lock allows you to lock the monitor and unlock it only after connecting a USB stick with the appropriate unlock file. The application for blocking the monitor will protect it just like the phone to the code. Both solutions protect the hardware and data available on it against unwanted use.
Avtek TouchScreen Lite monitors come with an interactive Windows Note software that allows you to both prepare a lesson and support a business presentation. Note supports the same file format as the Android whiteboard application, so that the same file can be edited on the monitor and then completed in Note in Windows.
In addition to Note software, two more programs are included in the monitor: Connect and Capture. The first one is used for communication between the mobile device and the PC and allows, among other things, to send images in both directions and control the presentation. This makes remote control of the monitor from a computer simple and intuitive. Capture is a useful tool for recording and editing presentations or lectures. Allows you to record the desktop of your Windows computer and the image from the connected camera (or both at the same time). Capture also offers fast editing of content that can be saved, uploaded to the cloud or published on sites such as YouTube as a single video file.
The optional OPS PCs for the TouchScreen 5 Series are designed to create a high-performance, high-performance all-in-one system with the monitor. To purchase a monitor with a computer - check the monitor sets in AB's offer.
All Avtek OPS 4K computers are equipped with modern sixth generation Intel Skylake processors, ensuring trouble-free operation and high performance. The modern sixth generation i3 processor can be much faster than the second generation i7 processor. Thanks to this, the user can be sure that he buys a solution that will function efficiently for many years to come.
SSDs used in Avtek OPS 4K computers are not only several dozen times faster than traditional HDDs, but also more resistant to damage and extremely quiet. These features make them ideal for use in interactive monitors where speed and reliability are important.
Interactive monitors are ideal for scenarios with different requirements, so OPS computers are available in several variants. In education and for basic applications the economical Celeron or i3 will be ideal. For more advanced applications, there are i5 versions, and for the most professional applications, the extremely powerful Intel i7.
Importantly, all versions support native resolution of Lite series monitors - 4K@60Hz.
Характеристики
Model:
AVTEK TouchScreen 5 LITE 55
Aspect ratio: 16:9
Screen size (diag.): 55"
Matrix type: TFT IPS
Display surface: Matt
Touch screen: Да
Transreflective technology: LED
Visible area, vertical: 608.4 mm
Visible area, horizontal: 1209.6 mm
Dot pitch: 0.315 mm
Резолюция: 3840 x 2160
Response time: 8 ms
Яркост: 300 cd/m²
Static contrast: 4 000:1
Viewing angle, horizontal: 178 °
Viewing angle, vertical: 178 °
Number of colors: 1,07 mld
I/O connectors: 3 x USB 2.0
1 x RS-232 (COM)
1 x RJ-45 LAN
1 x USB 3.0
1 x Audio in
1 x Audio out
2 x HDMI
1 x 15-pin D-Sub
Speakers built-in: Да
TV tuner built-in: Не
Auto Pivot: Не
Сертификати: RoHS
ISO 14001
CE
ISO 9001
VESA: 400 x 400
Power consumption: 250 W
Accessories included:
power cable (3 m), VGA cable (3 m), USB cable (5 m), audio cable mj 3.5 mm (5 m), dummy recorder (3 pcs), remote control, quick start guide PL, plate CD or pendrive with software and drivers
Цвят: Черен
Височина: 765.2 mm
Ширина: 1268.4 mm
Дълбочина: 112.4 mm
Тегло, kg: 30 kg
Other features:
Specification of the Android module
System version: 7.0
system resolution: Full HD
CPU: ARM Cortex A73 Dual Core CPU
GPU: Mali-450
RAM: 2 GB
ROM: 16 GB
Information about the software
menu language OSD / Android: Polish / English / German
application for applying notes: Yes, in version 2.0
listing on any source: Yes, two modes
the ability to upload your own logo: Yes
possibility to change the name of the signal source: Yes
built-in voting tools: Yes
the ability to display text comments on the screen by participants: Yes
Windows software compatible with the application for applying notes: Yes, Note software
Warranty:
3 years after free registration at
Description
The new generation of Android 7.0 offers faster components and a higher version of the operating system, which makes support for the monitor even smoother and will allow you to install more demanding applications.
A built-in application (inactive version) for wireless video streaming allows you to connect to 8 computers or mobile devices at once and display up to four images at the same time. Wireless transmission of video, sound and touch makes cooperation even more convenient and eliminates the need to connect each computer directly to a monitor. In addition, it is possible to extend it by Avtek Share, a hardware solution that will allow you to connect to your computer without installing additional software on it, connect the dongle to the USB port and press the button.
Over-the-air software updates keep your monitor up to date with the latest features and applications over time. The user will easily install the update when it is available and will not be bypassed by future changes.
TouchScreen 5 monitors are fully prepared to support 4K/UHD resolution. The advanced LG panel with 3840 x 2160 resolution and 60Hz refresh rate is responsible for displaying the image. The chassis features a new, faster OPS connector for an optional PC and HDMI 2. 0 ports for connecting any modern equipment.
Thanks to the unique solution of shared USB ports on the front of the monitor, once connected to the USB stick will be available on both Android and the built-in OPS computer without the need to move between ports.
The new version of the note taking tool in the Lite series not only allows you to mark notes on any image or monitor like an interactive whiteboard, but it is also equipped with additional tools to help with presentations, lessons and meetings, e. g. stopwatch, timer, spotlight and voting system.
The voting tool called from the pop-up shortcut bar available on each source allows you to ask any question, collect answers and discuss them quickly. And it doesn't matter if you're viewing a presentation, an Android browser or an image from an external source like a laptop.
The monitor lockout features are dedicated to the school environment and are suitable for use in crowded areas. USB Disk Lock allows you to lock the monitor and unlock it only after connecting a USB stick with the appropriate unlock file. The application for blocking the monitor will protect it just like the phone to the code. Both solutions protect the hardware and data available on it against unwanted use.
Avtek TouchScreen Lite monitors come with an interactive Windows Note software that allows you to both prepare a lesson and support a business presentation. Note supports the same file format as the Android whiteboard application, so that the same file can be edited on the monitor and then completed in Note in Windows.
In addition to Note software, two more programs are included in the monitor: Connect and Capture. The first one is used for communication between the mobile device and the PC and allows, among other things, to send images in both directions and control the presentation. This makes remote control of the monitor from a computer simple and intuitive. Capture is a useful tool for recording and editing presentations or lectures. Allows you to record the desktop of your Windows computer and the image from the connected camera (or both at the same time). Capture also offers fast editing of content that can be saved, uploaded to the cloud or published on sites such as YouTube as a single video file.
The optional OPS PCs for the TouchScreen 5 Series are designed to create a high-performance, high-performance all-in-one system with the monitor. To purchase a monitor with a computer - check the monitor sets in AB's offer.
All Avtek OPS 4K computers are equipped with modern sixth generation Intel Skylake processors, ensuring trouble-free operation and high performance. The modern sixth generation i3 processor can be much faster than the second generation i7 processor. Thanks to this, the user can be sure that he buys a solution that will function efficiently for many years to come.
SSDs used in Avtek OPS 4K computers are not only several dozen times faster than traditional HDDs, but also more resistant to damage and extremely quiet. These features make them ideal for use in interactive monitors where speed and reliability are important.
Interactive monitors are ideal for scenarios with different requirements, so OPS computers are available in several variants. In education and for basic applications the economical Celeron or i3 will be ideal. For more advanced applications, there are i5 versions, and for the most professional applications, the extremely powerful Intel i7.
Importantly, all versions support native resolution of Lite series monitors - 4K@60Hz.
Характеристики
Model:
AVTEK TouchScreen 5 LITE 55
Aspect ratio: 16:9
Screen size (diag.): 55"
Matrix type: TFT IPS
Display surface: Matt
Touch screen: Да
Transreflective technology: LED
Visible area, vertical: 608.4 mm
Visible area, horizontal: 1209.6 mm
Dot pitch: 0.315 mm
Резолюция: 3840 x 2160
Response time: 8 ms
Яркост: 300 cd/m²
Static contrast: 4 000:1
Viewing angle, horizontal: 178 °
Viewing angle, vertical: 178 °
Number of colors: 1,07 mld
I/O connectors: 3 x USB 2.0
1 x RS-232 (COM)
1 x RJ-45 LAN
1 x USB 3.0
1 x Audio in
1 x Audio out
2 x HDMI
1 x 15-pin D-Sub
Speakers built-in: Да
TV tuner built-in: Не
Auto Pivot: Не
Сертификати: RoHS
ISO 14001
CE
ISO 9001
VESA: 400 x 400
Power consumption: 250 W
Accessories included:
power cable (3 m), VGA cable (3 m), USB cable (5 m), audio cable mj 3.5 mm (5 m), dummy recorder (3 pcs), remote control, quick start guide PL, plate CD or pendrive with software and drivers
Цвят: Черен
Височина: 765.2 mm
Ширина: 1268.4 mm
Дълбочина: 112.4 mm
Тегло, kg: 30 kg
Other features:
Specification of the Android module
System version: 7.0
system resolution: Full HD
CPU: ARM Cortex A73 Dual Core CPU
GPU: Mali-450
RAM: 2 GB
ROM: 16 GB
Information about the software
menu language OSD / Android: Polish / English / German
application for applying notes: Yes, in version 2.0
listing on any source: Yes, two modes
the ability to upload your own logo: Yes
possibility to change the name of the signal source: Yes
built-in voting tools: Yes
the ability to display text comments on the screen by participants: Yes
Windows software compatible with the application for applying notes: Yes, Note software
Warranty:
3 years after free registration at
